USB on-the-go full-speed (OTG_FS) RM0090

1071/1422 Doc ID 018909 Rev 4

OTG_FS Host periodic transmit FIFO size register (OTG_FS_HPTXFSIZ)

Address offset: 0x100

Reset value: 0x0200 0600

313029282726252423222120191817161514131211109876543210

PTXFSIZ PTXSA

r/r

Bits 31:16 PTXFD: Host periodic TxFIFO depth

This value is in terms of 32-bit words.

Minimum value is 16

Bits 15:0 PTXSA: Host periodic TxFIFO start address

The power-on reset value of this register is the sum of the largest Rx data FIFO depth and

largest non-periodic Tx data FIFO depth.
