RM0090 Memory and bus architecture
Doc ID 018909 Rev 4 54/1422
0x4001 3000 - 0x4001 33FF SPI1
APB2
Section 27.5.10: SPI register map on page 845
0x4001 2C00 - 0x4001 2FFF SDIO Section 28.9.16: SDIO register map on page 901
0x4001 2000 - 0x4001 23FF ADC1 - ADC2 - ADC3 Section 11.13.18: ADC register map on page 307
0x4001 1400 - 0x4001 17FF USART6
Section 26.6.8: USART register map on page 793
0x4001 1000 - 0x4001 13FF USART1
0x4001 0400 - 0x4001 07FF TIM8
Section 14.4.21: TIM1&TIM8 register map on
page 420
0x4001 0000 - 0x4001 03FF TIM1
0x4000 7C00 - 0x4000 7FFF UART8
APB1 Section 26.6.8: USART register map on page 793
0x4000 7800 - 0x4000 7BFF UART7
0x4000 7400 - 0x4000 77FF DAC
APB1
Section 12.5.15: DAC register map on page 329
0x4000 7000 - 0x4000 73FF PWR Section 5.5: PWR register map on page 109
0x4000 6800 - 0x4000 6BFF CAN2
Section 24.9.5: bxCAN register map on page 705
0x4000 6400 - 0x4000 67FF CAN1
0x4000 5C00 - 0x4000 5FFF I2C3
Section 25.6.11: I2C register map on page 7410x4000 5800 - 0x4000 5BFF I2C2
0x4000 5400 - 0x4000 57FF I2C1
0x4000 5000 - 0x4000 53FF UART5
Section 26.6.8: USART register map on page 793
0x4000 4C00 - 0x4000 4FFF UART4
0x4000 4800 - 0x4000 4BFF USART3
0x4000 4400 - 0x4000 47FF USART2
0x4000 4000 - 0x4000 43FF I2S3ext
Section 27.5.10: SPI register map on page 845
0x4000 3C00 - 0x4000 3FFF SPI3 / I2S3
0x4000 3800 - 0x4000 3BFF SPI2 / I2S2
0x4000 3400 - 0x4000 37FF I2S2ext
0x4000 3000 - 0x4000 33FF IWDG Section 18.4.5: IWDG register map on page 540
0x4000 2C00 - 0x4000 2FFF WWDG Section 19.6.4: WWDG register map on page 547
0x4000 2800 - 0x4000 2BFF RTC & BKP Registers Section 23.6.21: RTC register map on page 662
0x4000 2000 - 0x4000 23FF TIM14
Section 16.6.11: TIM10/11/13/14 register map on
page 524
0x4000 1C00 - 0x4000 1FFF TIM13
0x4000 1800 - 0x4000 1BFF TIM12
Section 16.5.14: TIM9/12 register map on
page 514
0x4000 1400 - 0x4000 17FF TIM7
Section 17.4.9: TIM6&TIM7 register map on
page 535
0x4000 1000 - 0x4000 13FF TIM6
0x4000 0C00 - 0x4000 0FFF TIM5
Section 15.4.21: TIMx register map on page 480
0x4000 0800 - 0x4000 0BFF TIM4
0x4000 0400 - 0x4000 07FF TIM3
0x4000 0000 - 0x4000 03FF TIM2
Table 2. STM32F4xx register boundary addresses (continued)
Boundary address Peripheral Bus Register map
