ST STM32F40 Series User Manual

Memory and bus architecture RM0090
53/1422 Doc ID 018909 Rev 4
0x4004 0000 - 0x4007 FFFF USB OTG HS
AHB1
Section 31.12.6: OTG_HS register map on
page 1248
0x4002 9000 - 0x4002 93FF
ETHERNET MAC
Section 29.8.5: Ethernet register maps on
page 1017
0x4002 8C00 - 0x4002 8FFF
0x4002 8800 - 0x4002 8BFF
0x4002 8400 - 0x4002 87FF
0x4002 8000 - 0x4002 83FF
0x4002 6400 - 0x4002 67FF DMA2
Section 9.5.11: DMA register map on page 245
0x4002 6000 - 0x4002 63FF DMA1
0x4002 4000 - 0x4002 4FFF BKPSRAM
0x4002 3C00 - 0x4002 3FFF
Flash interface
register
Section 3.8: Flash interface registers
0x4002 3800 - 0x4002 3BFF RCC Section 6.3.32: RCC register map on page 181
0x4002 3000 - 0x4002 33FF CRC Section 4.4.4: CRC register map on page 88
0x4002 2000 - 0x4002 23FF GPIOI
Section 7.4.11: GPIO register map on page 203
0x4002 1C00 - 0x4002 1FFF GPIOH
0x4002 1800 - 0x4002 1BFF GPIOG
0x4002 1400 - 0x4002 17FF GPIOF
0x4002 1000 - 0x4002 13FF GPIOE
0x4002 0C00 - 0x4002 0FFF GPIOD
0x4002 0800 - 0x4002 0BFF GPIOC
0x4002 0400 - 0x4002 07FF GPIOB
0x4002 0000 - 0x4002 03FF GPIOA
0x4001 5400 - 0x4001 57FF SPI6
APB2 Section 27.5.10: SPI register map on page 845
0x4001 5000 - 0x4001 53FF SPI5
0x4001 4800 - 0x4001 4BFF TIM11
APB2
Section 16.6.11: TIM10/11/13/14 register map on
page 524
0x4001 4400 - 0x4001 47FF TIM10
0x4001 4000 - 0x4001 43FF TIM9
Section 16.5.14: TIM9/12 register map on
page 514
0x4001 3C00 - 0x4001 3FFF EXTI Section 10.3.7: EXTI register map on page 262
0x4001 3800 - 0x4001 3BFF SYSCFG Section 7.2.8: SYSCFG register maps on page 157
0x4001 3400 - 0x4001 37FF SPI4 APB2 Section 27.5.10: SPI register map on page 845
Table 2. STM32F4xx register boundary addresses (continued)
Boundary address Peripheral Bus Register map
