Controller area network (bxCAN) RM0090
707/1422 Doc ID 018909 Rev 4
0x200
CAN_FMR
Reserved
CAN2SB[5:0]
Reserved
FINIT
Reset value 001110 1
0x204
CAN_FM1R
Reserved
FBM[27:0]
Reset value 0000000000000000000000000000
0x208 Reserved
0x20C
CAN_FS1R
Reserved
FSC[27:0]
Reset value 0000000000000000000000000000
0x210 Reserved
0x214
CAN_FFA1R
Reserved
FFA[27:0]
Reset value 0000000000000000000000000000
0x218 Reserved
0x21C
CAN_FA1R
Reserved
FACT[27:0]
Reset value 0000000000000000000000000000
0x220
Reserved
0x224-
0x23F
Reserved
0x240
CAN_F0R1 FB[31:0]
Reset value xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
0x244
CAN_F0R2 FB[31:0]
Reset value xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
0x248
CAN_F1R1 FB[31:0]
Reset value xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
0x24C
CAN_F1R2 FB[31:0]
Reset value xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
.
.
.
.
.
.
.
.
.
.
.
.
0x318
CAN_F27R1 FB[31:0]
Reset value xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
0x31C
CAN_F27R2 FB[31:0]
Reset value xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
Table 102. bxCAN register map and reset values (continued)
Offset Register
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
