4-24 Phaser 6180MFP Multifunction Printer Service Manual
General Troubleshooting
Display
Counter
Display Counter
■ ON *
■ OFF
<Press the Up or Down
button to switch Display
Counter On/Off>
<Press the OK button to
save the setting and
move one level up the
menu>
<Press the Exit button to
move one level up the
menu without saving the
value>
Displays the current Display Counter
On/Off information and sets mode On/
Off.
Note: This information is not initialized
with any key action.
Hex Dump HexDump
■ OFF *
■ ON
<Press the Up or Down
button to switch
HexDump On/Off>
<Press the OK button to
save the setting and
move one level up the
menu>
<Press the Exit button to
move one level up the
menu without saving the
value>
Displays the current HexDump On/Off
information and sets mode On/Off.
Note: This information is initialized by
Clear All NVM.
Note: When the Counter Type has been
changed, an “*” is displayed next to
the text.
Pixel Counter Pixel Counter
■ Y: nn.n
■ C: nn.n
■ M: nn.n
■ K: nn.n
<Press the OK or Exit
button to move one level
up the menu>
Displays the ratio (% used) of the
number of pixel per C/M/Y/K counted
by the Controller to A4 size area except
4 mm area from the edge on the last
page print.
■ 100% = empty print cartridge
The value is rounded off to one decimal
place.
For B/W print, only K is displayed.
The ranges are from 0-100% for each
color (CMYK).
Configuration
(Do not use -
for
Development
Only)
Configuration
■ Dip Switch0
■ 00000000 *
■ Dip Switch1
■ 00000000 *
■ Dip Switch2
■ 00000000 *
■ Dip Switch3
■ 00000000 *
Operates the DIP switch on NVRAM of
the Controller.
Available values are 0 and 1.
Note: This information is initialized by
Clear All NVM.
Printer Diag Test Table (continued)
Test Control Panel Display Test Description
To Next Page
