Phaser 6180MFP Multifunction Printer Service Manual 4-23
General Troubleshooting
Info Page Info Page
Ready
Processing
Prints the software version of the
printer controller. Use this function to
verify the printer configuration. The
Configuration Page contains:
Engine installation unit information
Standard Tray
Optional Tray (displaying version)
Optional Duplex Unit (displaying
version)
Engine ROM Revision No.
MCU NVM Revision No.
Print Settings Print Settings
Ready
Processing
Prints the configured settings through
the Control Panel.
The Print Settings page contains:
Serial No.
HexDump On/Off Information
Tone Correction On/Off Information
Color Print Count
B/W Print Count
Total Print Count
Color Backup Count
B/W Backup Count
Total Backup Count
Color Error Count
B/W Error Count
Installation Provides printer installation information.
Serial No. SerialNo.
GNXxxxxxx
or
GPXxxxxxx
Displays the 6 digit Serial Number.
Note: This information is not initialized
with any key action.
Tone Correction Tone Correction
ON *
OFF
<Press the Up or Down
button to switch Tone
Correction On/Off>
<Press the OK button to
save the setting and
move one level up the
menu>
<Press the Exit button to
move one level up the
menu without saving the
value>
Controls TRC in conjunction with
process control to keep the printer
density constant. This function is
implemented to turn Off tone
correction control in case correction
exceeds the limit due to machine-to-
machine variation.
Sets the printer Tone Correction mode
On/Off.
Note: When the Tone Correction has
been changed, an “*” is displayed next
to the text.
Note: This information can be
initialized by Initialize NVM (System >
Admin Menu > Maintenance >
Initialize NVM).
Printer Diag Test Table (continued)
Test Control Panel Display Test Description
