Xerox Phaser 6180MFP Service Manual

4-28 Phaser 6180MFP Multifunction Printer Service Manual
General Troubleshooting
Print Counter
Scan Service
SMB/FTP
■ n
Email
■ n
SMB/FTP Backup
■ n
Email Backup
■ n
SMB/FTP Error
■ n
Email Error
■ n
Copy Counter
MtoB
CopyCounter MtoB
■ OK?
■ Processing
■ Copied
<Press the Exit button to
move one level up the
menu>
<Press the OK button to
run the test>
Copies the values from Master NVRAM
to Backup NVRAM.
■ Device-specific information called *
■ “Personal info” in the first 128 Byte
■ PV counter master
■ Printer counter master
Copy Counter
BtoM
CopyCounter BtoM
■ OK?
■ Processing
■ Copied
<Press the Exit button to
move one level up the
menu>
<Press the OK button to
run the test>
Copies the values from Backup NVRAM
to Master NVRAM.
■ Device-specific information called
“Personal info” in the first 128 Byte.
■ PV counter backup
■ Printer counter backup
Clear All NVM Clear All NVM
■ OK?
■ Processing
■ Initialized
<Press the Exit button to
move one level up the
menu>
<Press the OK button to
run the test>
Clears all NVRAM of the Controller
including billing.
Printer Diag Test Table (continued)
Test Control Panel Display Test Description

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
