Xerox Phaser 6180MFP - Page 443

Phaser 6180MFP Multifunction Printer Service Manual 4-31
General Troubleshooting
Slow Scan
1200C
Slow Scan 1200C
■ -60 *
■ :
■ 60 *
Fast Scan KtoM Fast Scan KtoM
■ -30 *
■ :
■ 30 *
Sets the registration in the scanning
direction for Tray 1 (MPT), Tray 2, Tray
3, and Duplex Unit.
Fast Scan KtoY Fast Scan KtoY
■ -30 *
■ :
■ 30 *
Fast Scan KtoC Fast Scan KtoC
■ -30 *
■ :
■ 30 *
Fast Scan
Tray 1 (MPT)
Fast Scan MPT
■ -30 *
■ :
■ 30 *
Fast Scan
Tray 2
Fast Scan Tray 2
■ -30 *
■ :
■ 30 *
Fast Scan
Tray 3
Fast Scan Tray 3
■ -30 *
■ :
■ 30 *
Fast Scan
Duplex
Fast Scan Duplex
■ -30 *
■ :
■ 30 *
Fast Scan 2
KtoM
Fast Scan 2 KtoM
■ -1 *
■ :
■ 2 *
Fast Scan 2
KtoY
Fast Scan 2 KtoY
■ -1 *
■ :
■ 2 *
Fast Scan 2
KtoC
Fast Scan 2 KtoC
■ -1 *
■ :
■ 2 *
Printer Diag Test Table (continued)
Test Control Panel Display Test Description
