Xerox Phaser 6180MFP Service Manual

10-46 Phaser 6180MFP Multifunction Printer Service Manual
Plug/Jack and Wiring Diagrams
Signal Line Name Description
TRAY SEN Controls signal of the Optional Feeder Board.
Rxd
Txd
TURN CL ON (L) +24 VDC On/Off signal of the Optional Turn Clutch.
FEED CL ON (L) +24 VDC On/Off signal of the Feed Clutch.
PAPER EMTY SENSED (L)
+3.3 VDC
Detects signal of the Feeder by the Photo Sensor (Tray
3 No Paper Sensor).
PAPER SIZE SW 1 ON (L)
+3.3 VDC
On/Off signal of the Optional Size Switch Assembly.
PAPER SIZE SW 2 ON (L)
+3.3 VDC
PAPER SIZE SW 3 ON (L)
+3.3 VDC
FEED MOT ON Drives control signal of the Feed Motor.
FEED MOT ALARM
FEED MOT CLK
FEED MOT LOW

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
