Enter/Exit Programming Mode

Product Reference Guide

145

PIR/CT Auxiliary Port Baud Rate (continued)

051607(CR)

PIR/CT Auxiliary Port Baud Rate = 57600

051608(CR)

PIR/CT Auxiliary Port Baud Rate = 115200
