Figure 15. Typical Checkstand Design & Cutout Location
2
3
5
10
9
6
7
8
CAPACITY / CAPACITE - 30 X .01 lb / 15 x .005 kg
0.00
lb
1
4
1
Conveyor
6
Top Down Reader (TDR) (optional)
2
Remote Display
7
Bagging Area
3
POS Terminal and Printer
8
Bag Well
4
Keyboard
9
Check Writing Stand (optional)
5
Scanner or Scanning-Scale
10
Item Diverter (optional)
