Product Reference Guide 429
UPC-E with 2-Digit Supplemental
• Number system must be included in label data
• Check digit must be included in label data and is assumed to be correct
• Supplemental data is appended to base label
• Prefix must be an ASCII character ‘E’ - total length including prefix must be 11
• Example: ‘E0998875012’
UPC-E with 5-Digit Supplemental
• Number system must be included in label data
• Check digit must be included in label data and is assumed to be correct
• Prefix must be an ASCII character ‘E’ - total length including prefix must be 14
• Example: ‘E0998875012345’
UPC-E with Code128 Supplemental
• Number system must be included in label data
• Check digit must be included in label data and is assumed to be correct
• Supplemental data is appended to base label
• Prefix must be an ASCII character ‘E’ - total length including prefix must be greater or
equal to 15 (code 128 supplemental codes are variable length having a minimum of 2
data characters)
• Characters immediately following base label must be of the form ‘8100’, ‘8101’ or
‘8102’
• Example: ‘E099887508101000951’
EAN8
• Check digit must be included in label data and is assumed to be correct
• Prefix must be an ASCII characters ‘FF’ - total length including prefix must be 10
• Example: ‘FF00210126’
EAN8 with 2-Digit Supplemental
• Check digit must be included in label data and is assumed to be correct
• Supplemental data is appended to base label
• Prefix must be an ASCII characters ‘FF’ - total length including prefix must be 12
• Example: ‘FF0021012612’
EAN8 with 5-Digit Supplemental
• Check digit must be included in label data and is assumed to be correct
• Prefix must be an ASCII characters ‘FF’ - total length including prefix must be 15
• Example: ‘FF0021012612345’

Datalogic Magellan 9800i Specifications

General

Type	Built-in bar code reader
Sensor type	-
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Power consumption (typical)	12 W
Standard interfaces	RS-232
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Built-in display	No

Weight and Dimensions

Weight	- g
