MPC5604B/C Microcontroller Reference Manual, Rev. 8
Freescale Semiconductor 407
21.7.1.20 Identifier filter control register (IFCR2n)
NOTE
This register can be written in Initialization mode only.
IFM[7] 0 Filters 14 and 15 are in identifier list mode.
1 Filters 14 and 15 are in mask mode (filter 15 is the mask for the filter 14).
Offsets : 0x004C–0x0084 (8 registers) Access: User read/write
0123456789101112131415
R 0000000000000000
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R 000
DFL DIR CCS
00 ID
W w1c
Reset0000000000000000
Figure 21-25. Identifier filter control register (IFCR2n)
Table 21-28. IFCR2n
field descriptions
Field Description
DFL Data Field Length
This field defines the number of data bytes in the response part of the frame.
DIR Direction
This bit controls the direction of the data field.
0 LINFlex receives the data and copies them in the BDRL and BDRM registers.
1 LINFlex transmits the data from the BDRL and BDRM registers.
CCS Classic Checksum
This bit controls the type of checksum applied on the current message.
0 Enhanced Checksum covering Identifier and Data fields. This is compatible with LIN specification
2.0 and higher.
1 Classic Checksum covering Data fields only. This is compatible with LIN specification 1.3 and
earlier.
ID Identifier
Identifier part of the identifier field without the identifier parity.
Table 21-27. IFMR[IFM] configuration (continued)
Bit Value Result
