the ADC allows channels to be monitored and if the results fall outwith a specific range an interrupt is
triggered. This means that all of the measurement is without CPU intervention if the results are within
range.
To make it easier to plan which pins to use for the eMIOS, Table 24-1 and Table 24-2 show the eMIOS
channel numbers that are available on each pin. The color shading matches the channel configuration
diagram in the eMIOS section.
Table 24-1. eMIOS_0 channel to pin mapping
Channel
Pin function
Channel
Pin function
ALT1 ALT2 ALT3 ALT1 ALT2 ALT3
UC[0] PA [0] UC[16] PE[0]
UC[1] PA [1] UC[17] PE[1]
UC[2] PA [2] UC[18] PE[2]
UC[3] PA[3], PB[11] UC[19] PE[3]
UC[4] PA[4], PB[12] UC[20] PE[4]
UC[5] PA[5], PB[13] UC[21] PE[5]
UC[6] PA[6], PB[14] UC[22] PE[6], PF[5] PE[8]
UC[7] PA[7], PB[15] UC[23] PE[7], PF[6] PE[9]
UC[8] PA [8] UC[24] PG[10] PD[12]
UC[9] PA [9] UC[25] PG[11] PD[13]
UC[10] PA[10], PF[0] UC[26] PG[12] PD[14]
UC[11] PA[11], PF[1] UC[27] PG[13] PD[15]
UC[12] PC[12], PF[2]
UC[13] PC[13], PF[3]
UC[14] PC[14], PF[4]
UC[15] PC[15]
Table 24-2. eMIOS_1 channel to pin mapping
Channel
Pin function
Channel
Pin function
ALT1 ALT2 ALT3 ALT1 ALT2 ALT3
UC[0] PG[14] UC[16] PG[7]
UC[1] PG[15] UC[17] PG[8]
UC[2] PH[0] UC[18] PG[9]
UC[3] PH[1] UC[19] PE[12]
UC[4] PH[2] UC[20] PE[13]
UC[5] PH[3] PH[11] UC[21] PE[14]
UC[6] PH[4] UC[22] PE[15]
UC[7] PH[5] UC[23] PG[0]
UC[8] PH[6] UC[24] PG[1]
UC[9] PH[7] UC[25] PF[12]
UC[10] PH[8] UC[26] PF[13]
UC[11] PG[2] UC[27] PF[14]
