Fujitsu PRIMERGY RX2540 M4

RX2540 M4 Upgrade and Maintenance Manual 419
Accessible drives
Figure 299: Installing the LTO (B)
Ê Thread the cables of the front panel, see section "Installing the ODD" on
page 393.
Ê Carefully slide in the front panel module into its bay.
