IA-32 Intel® Architecture Optimization
2-40
Cache line size for Pentium 4 and Pentium M processors can impact
streaming applications (for example, multimedia). These reference and
use data only once before discarding it. Data accesses which sparsely
utilize the data within a cache line can result in less efficient utilization
of system memory bandwidth. For example, arrays of structures can be
decomposed into several arrays to achieve better packing, as shown in
Example 2-19.
The efficiency of such optimizations depends on usage patterns. If the
elements of the structure are all accessed together but the access pattern
of the array is random, then
array_of_struct avoids unnecessary
prefetch even though it wastes memory.
Example 2-19 Decomposing an Array
struct {/* 1600 bytes */
int a, c, e;
char b, d;
} array_of_struct [100];
struct {/* 1400 bytes */
int a[100], c[100], e[100];
char b[100], d[100];
} struct_of_array;
struct {/* 1200 bytes */
int a, c, e;
} hybrid_struct_of_array_ace[100];
struct {/* 200 bytes */
char b, d;
} hybrid_struct_of_array_bd[100];

Intel ARCHITECTURE IA-32 Specifications

General

Instruction Set	x86
Instruction Set Type	CISC
Memory Segmentation	Supported
Operating Modes	Real mode, Protected mode, Virtual 8086 mode
Max Physical Address Size	36 bits (with PAE)
Max Virtual Address Size	32 bits
Architecture	IA-32 (Intel Architecture 32-bit)
Addressable Memory	4 GB (with Physical Address Extension up to 64 GB)
Floating Point Registers	8 x 80-bit
MMX Registers	8 x 64-bit
SSE Registers	8 x 128-bit
Registers	General-purpose registers (EAX, EBX, ECX, EDX, ESI, EDI, ESP, EBP), Segment registers (CS, DS, SS, ES, FS, GS), Instruction pointer (EIP), Flags register (EFLAGS)
Floating Point Unit	Yes (x87)
