IA-32 Intel® Architecture Optimization
3-14
The examples that follow illustrate the use of coding adjustments to
enable the algorithm to benefit from the SSE. The same techniques may
be used for single-precision floating-point, double-precision
floating-point, and integer data under SSE2, SSE, and MMX
technology.
As a basis for the usage model discussed in this section, consider a
simple loop shown in Example 3-8.
Note that the loop runs for only four iterations. This allows a simple
replacement of the code with Streaming SIMD Extensions.
For the optimal use of the Streaming SIMD Extensions that need data
alignment on the 16-byte boundary, all examples in this chapter assume
that the arrays passed to the routine,
a, b, c, are aligned to 16-byte
boundaries by a calling routine. For the methods to ensure this
alignment, please refer to the application notes for the Pentium 4
processor.
The sections that follow provide details on the coding methodologies:
inlined assembly, intrinsics, C++ vector classes, and automatic
vectorization.
Example 3-8 Simple Four-Iteration Loop
void add(float *a, float *b, float *c)
{
int i;
for (i = 0; i < 4; i++) {
c[i] = a[i] + b[i];
}
}

Intel ARCHITECTURE IA-32 Specifications

General

Instruction Set	x86
Instruction Set Type	CISC
Memory Segmentation	Supported
Operating Modes	Real mode, Protected mode, Virtual 8086 mode
Max Physical Address Size	36 bits (with PAE)
Max Virtual Address Size	32 bits
Architecture	IA-32 (Intel Architecture 32-bit)
Addressable Memory	4 GB (with Physical Address Extension up to 64 GB)
Floating Point Registers	8 x 80-bit
MMX Registers	8 x 64-bit
SSE Registers	8 x 128-bit
Registers	General-purpose registers (EAX, EBX, ECX, EDX, ESI, EDI, ESP, EBP), Segment registers (CS, DS, SS, ES, FS, GS), Instruction pointer (EIP), Flags register (EFLAGS)
Floating Point Unit	Yes (x87)
