Intel ARCHITECTURE IA-32 User Manual

IA-32 Instruction Latency and Throughput C
C-9
PSUBB/PSUBW/PSUBD
xmm, xmm
2 2 1 2 2 1 MMX_ALU
PSUBSB/PSUBSW/PSUBU
SB/PSUBUSW xmm, xmm
2 2 1 2 2 1 MMX_ALU
PUNPCKHBW/PUNPCKH
WD/PUNPCKHDQ xmm,
xmm
4 4 1+1 2 2 2 MMX_SHFT
PUNPCKHQDQ xmm, xmm 4 4 1_1 2 2 2 MMX_SHFT
PUNPCKLBW/PUNPCKLW
D/PUNPCKLDQ xmm, xmm
2 2 2 2 2 2 MMX_SHFT
PUNPCKLQDQ
3
xmm,
xmm
44 1 11 1FP_MISC
PXOR xmm, xmm 2 2 1 2 2 1 MMX_ALU
See “Table Footnotes”
Table C-3 Streaming SIMD Extension 2 Double-precision Floating-point
Instructions
Instruction Latency
1
Throughput
Execution
Unit
2
CPUID 0F3n 0F2n 0x69n 0F3n 0F2n 0x69n 0F2n
ADDPD xmm, xmm 5 4 4 2 2 2 FP_ADD
ADDSD xmm, xmm 5 4 3 2 2 1 FP_ADD
ANDNPD
3
xmm, xmm 4 4 1 2 2 1 MMX_ALU
ANDPD
3
xmm, xmm 4 4 1 2 2 1 MMX_ALU
CMPPD xmm, xmm,
imm8
54 4 22 2FP_ADD
CMPSD xmm, xmm,
imm8
54 3 22 1FP_ADD
continued
Table C-2 Streaming SIMD Extension 2 128-bit Integer Instructions (continued)
Instruction Latency
1
Throughput
Execution
Unit
2

Intel ARCHITECTURE IA-32 Specifications

General

Instruction Set	x86
Instruction Set Type	CISC
Memory Segmentation	Supported
Operating Modes	Real mode, Protected mode, Virtual 8086 mode
Max Physical Address Size	36 bits (with PAE)
Max Virtual Address Size	32 bits
Architecture	IA-32 (Intel Architecture 32-bit)
Addressable Memory	4 GB (with Physical Address Extension up to 64 GB)
Floating Point Registers	8 x 80-bit
MMX Registers	8 x 64-bit
SSE Registers	8 x 128-bit
Registers	General-purpose registers (EAX, EBX, ECX, EDX, ESI, EDI, ESP, EBP), Segment registers (CS, DS, SS, ES, FS, GS), Instruction pointer (EIP), Flags register (EFLAGS)
Floating Point Unit	Yes (x87)
