Mathematics of Prefetch Scheduling Distance E
E-3
T
b
data transfer latency which is equal to number of lines
per iteration * line burst latency
Note that the potential effects of µop reordering are not factored into the
estimations discussed.
Examine Example E-1 that uses the
prefetchnta instruction with a
prefetch scheduling distance of 3, that is, psd = 3. The data prefetched in
iteration i, will actually be used in iteration i+3. T
c
represents the cycles
needed to execute
top_loop - assuming all the memory accesses hit L1
while il (iteration latency) represents the cycles needed to execute this
loop with actually run-time memory footprint. T
c
can be determined by
computing the critical path latency of the code dependency graph. This
work is quite arduous without help from special performance
characterization tools or compilers. A simple heuristic for estimating the
T
c
value is to count the number of instructions in the critical path and
multiply the number with an artificial CPI. A reasonable CPI value
would be somewhere between 1.0 and 1.5 depending on the quality of
code scheduling.
Example E-1 Calculating Insertion for Scheduling Distance of 3
top_loop:
prefetchnta [edx+esi+32*3]
prefetchnta [edx*4+esi+32*3]
. . . . .
movaps xmm1, [edx+esi]
movaps xmm2, [edx*4+esi]
movaps xmm3, [edx+esi+16]
movaps xmm4, [edx*4+esi+16]
. . . . .
. . .
add esi, 32
cmp esi, ecx
jl top_loop

Intel ARCHITECTURE IA-32 Specifications

General

Instruction Set	x86
Instruction Set Type	CISC
Memory Segmentation	Supported
Operating Modes	Real mode, Protected mode, Virtual 8086 mode
Max Physical Address Size	36 bits (with PAE)
Max Virtual Address Size	32 bits
Architecture	IA-32 (Intel Architecture 32-bit)
Addressable Memory	4 GB (with Physical Address Extension up to 64 GB)
Floating Point Registers	8 x 80-bit
MMX Registers	8 x 64-bit
SSE Registers	8 x 128-bit
Registers	General-purpose registers (EAX, EBX, ECX, EDX, ESI, EDI, ESP, EBP), Segment registers (CS, DS, SS, ES, FS, GS), Instruction pointer (EIP), Flags register (EFLAGS)
Floating Point Unit	Yes (x87)
