Intel ARCHITECTURE IA-32 User Manual

Multi-Core and Hyper-Threading Technology 7
7-51
Affinity masks can be used to optimize shared multi-threading
resources.
Example 7-11 Assembling 3-level IDs, Affinity Masks for Each Logical
Processor
// The BIOS and/or OS may limit the number of logical processors
// available to applications after system boot.
// The below algorithm will compute topology for the logical processors
// visible to the thread that is computing it.
// Extract the 3-levels of IDs on every processor.
// SystemAffinity is a bitmask of all the processors started by the OS.
// Use OS specific APIs to obtain it.
// ThreadAffinityMask is used to affinitize the topology enumeration
// thread to each processor using OS specific APIs.
// Allocate per processor arrays to store the Package_ID, Core_ID and
// SMT_ID for every started processor.
typedef struct {
AFFINITYMASK affinity_mask; // 8 byte in 64-bit mode,
// 4 byte otherwise.
unsigned char smt;
; unsigned char core;
unsigned char pkg;
unsigned char initialAPIC_ID;
} APIC_MAP_T;
APIC_MAP_T apic_conf[64];
ThreadAffinityMask = 1;
ProcessorNum = 0;
while (ThreadAffinityMask != 0 && ThreadAffinityMask <=
SystemAffinity) {
// Check to make sure we can utilize this processor first.

Intel ARCHITECTURE IA-32 Specifications

General

Instruction Set	x86
Instruction Set Type	CISC
Memory Segmentation	Supported
Operating Modes	Real mode, Protected mode, Virtual 8086 mode
Max Physical Address Size	36 bits (with PAE)
Max Virtual Address Size	32 bits
Architecture	IA-32 (Intel Architecture 32-bit)
Addressable Memory	4 GB (with Physical Address Extension up to 64 GB)
Floating Point Registers	8 x 80-bit
MMX Registers	8 x 64-bit
SSE Registers	8 x 128-bit
Registers	General-purpose registers (EAX, EBX, ECX, EDX, ESI, EDI, ESP, EBP), Segment registers (CS, DS, SS, ES, FS, GS), Instruction pointer (EIP), Flags register (EFLAGS)
Floating Point Unit	Yes (x87)
