Multi-Core and Hyper-Threading Technology 7
7-55
Example 7-13 Discovering the Affinity Masks for Sibling Logical Processors
Sharing the Same Cache
// Logical processors sharing the same cache can be determined by bucketing
// the logical processors with a mask, the width of the mask is determined
// from the maximum number of logical processors sharing that cache level.
// The algorithm below assumes that all processors have identical cache hierarchy
// and initial APIC ID assignment across the modular
// boundary of the logical processor sharing the target level cache must respect
// bit-field boundary. This is a requirement similar to those applying to
// core boundary and package boundary. The modular boundary of those
// logical processors sharing the target level cache may coincide with core
// boundary or above core boundary.
ThreadAffinityMask = 1;
ProcessorNum = 0;
while (ThreadAffinityMask != 0 && ThreadAffinityMask <=
SystemAffinity) {
// Check to make sure we can utilize this processor first.
if (ThreadAffinityMask & SystemAffinity){
Set thread to run on the processor specified in
ThreadAffinityMask.
Wait if necessary and ensure thread is running on specified
processor.
initialAPIC_ID = GetInitialAPIC_ID();
Extract the Package, Core and SMT ID as explained in
three level extraction algorithm.
Extract the CACHE_ID similar to the PACKAGE_ID extraction algorithm.
// Cache topology may vary for each cache level, one mask for each level.
// The target level is selected by the input value index
CacheIDMask = ((uchar) (0xff <<
FindMaskWidth(MaxLPSharingCache(TargetLevel))); // See Example 7-9.
CACHE_ID = InitialAPIC_ID & CacheIDMask;

Intel ARCHITECTURE IA-32 Specifications

General

Instruction Set	x86
Instruction Set Type	CISC
Memory Segmentation	Supported
Operating Modes	Real mode, Protected mode, Virtual 8086 mode
Max Physical Address Size	36 bits (with PAE)
Max Virtual Address Size	32 bits
Architecture	IA-32 (Intel Architecture 32-bit)
Addressable Memory	4 GB (with Physical Address Extension up to 64 GB)
Floating Point Registers	8 x 80-bit
MMX Registers	8 x 64-bit
SSE Registers	8 x 128-bit
Registers	General-purpose registers (EAX, EBX, ECX, EDX, ESI, EDI, ESP, EBP), Segment registers (CS, DS, SS, ES, FS, GS), Instruction pointer (EIP), Flags register (EFLAGS)
Floating Point Unit	Yes (x87)
