Intel ARCHITECTURE IA-32 User Manual

Optimizing for SIMD Floating-point Applications 5
5-17
Using MMX Technology Code for Copy or Shuffling
Functions
If there are some parts in the code that are mainly copying, shuffling, or
doing logical manipulations that do not require use of SSE code,
consider performing these actions with MMX technology code. For
example, if texture data is stored in memory as SoA (
uuuu, vvvv) and
they need only to be deswizzled into AoS layout (
uv) for the graphic
cards to process, you can use either the SSE or MMX technology code.
Using the MMX instructions allow you to conserve XMM registers for
other computational tasks.
movq mm1, [ebx+16] // mm1= v1 v2
movq mm2, mm0 // mm2= u1 u2
punpckhdq mm0, mm1 // mm0= u1 v1
punpckldq mm2, mm1 // mm0= u2 v2
movq [edx], mm2 // store u1 v1
movq [edx+8], mm0 // store u2 v2
movq mm4, [ebx+8] // mm0= u3 u4
movq mm5, [ebx+24] // mm1= v3 v4
movq mm6, mm4 // mm2= u3 u4
punpckhdq mm4, mm5 // mm0= u3 v3
punpckldq mm6, mm5 // mm0= u4 v4
movq [edx+16], mm6 // store u3v3
movq [edx+24], mm4 // store u4v4
}
Example 5-7 Deswizzling Data 64-bit Integer SIMD Data (continued)

Intel ARCHITECTURE IA-32 Specifications

General

Instruction Set	x86
Instruction Set Type	CISC
Memory Segmentation	Supported
Operating Modes	Real mode, Protected mode, Virtual 8086 mode
Max Physical Address Size	36 bits (with PAE)
Max Virtual Address Size	32 bits
Architecture	IA-32 (Intel Architecture 32-bit)
Addressable Memory	4 GB (with Physical Address Extension up to 64 GB)
Floating Point Registers	8 x 80-bit
MMX Registers	8 x 64-bit
SSE Registers	8 x 128-bit
Registers	General-purpose registers (EAX, EBX, ECX, EDX, ESI, EDI, ESP, EBP), Segment registers (CS, DS, SS, ES, FS, GS), Instruction pointer (EIP), Flags register (EFLAGS)
Floating Point Unit	Yes (x87)
