Intel ARCHITECTURE IA-32 User Manual

IA-32 Intel® Architecture Optimization
6-38
Without strip-mining, all the x,y,z coordinates for the four vertices must
be re-fetched from memory in the second pass, that is, the lighting loop.
This causes under-utilization of cache lines fetched during
transformation loop as well as bandwidth wasted in the lighting loop.
Now consider the code in Example 6-8 where strip-mining has been
incorporated into the loops.
With strip-mining, all the vertex data can be kept in the cache (for
example, one way of second-level cache) during the strip-mined
transformation loop and reused in the lighting loop. Keeping data in the
cache reduces both bus traffic and the number of prefetches used.
Example 6-8 Data Access of a 3D Geometry Engine with Strip-mining
while (nstrip < NUM_STRIP) {
/* Strip-mine the loop to fit data into one way of the second-level
cache */
while (nvtx < MAX_NUM_VTX_PER_STRIP) {
prefetchnta vertex
i
data // v=[x,y,z,nx,ny,nz,tu,tv]
prefetchnta vertex
i+1
data
prefetchnta vertex
i+2
data
prefetchnta vertex
i+3
data
TRANSFORMATION code
nvtx+=4
}
while (nvtx < MAX_NUM_VTX_PER_STRIP) {
/* x y z coordinates are in the second-level cache, no prefetch
is
required */
compute the light vectors
POINT LIGHTING code
nvtx+=4
}
}

Intel ARCHITECTURE IA-32 Specifications

General

Instruction Set	x86
Instruction Set Type	CISC
Memory Segmentation	Supported
Operating Modes	Real mode, Protected mode, Virtual 8086 mode
Max Physical Address Size	36 bits (with PAE)
Max Virtual Address Size	32 bits
Architecture	IA-32 (Intel Architecture 32-bit)
Addressable Memory	4 GB (with Physical Address Extension up to 64 GB)
Floating Point Registers	8 x 80-bit
MMX Registers	8 x 64-bit
SSE Registers	8 x 128-bit
Registers	General-purpose registers (EAX, EBX, ECX, EDX, ESI, EDI, ESP, EBP), Segment registers (CS, DS, SS, ES, FS, GS), Instruction pointer (EIP), Flags register (EFLAGS)
Floating Point Unit	Yes (x87)
