Intel ARCHITECTURE IA-32 User Manual

Multi-Core and Hyper-Threading Technology 7
7-13
Example 7-3 Thread Function for an Interlaced Producer Consumer Model
// master thread starts the first iteration, the other thread must wait
// one iteration
void producer_consumer_thread(int master)
{
int mode = 1 - master; // track which thread and its designated buffer index
unsigned int iter_num = workamount >> 1;
unsigned int i=0;
iter_num += master & workamount & 1;
if (master) // master thread starts the first iteration
{
produce(buffs[mode],count);
Signal(sigp[1-mode],1); // notify the producer task in follower thread
// that it can proceed
consume(buffs[mode],count);
Signal(sigc[1-mode],1);
i = 1;
}
for (; i < iter_num; i++)
{
WaitForSignal(sigp[mode]);
produce(buffs[mode],count); // notify the producer task in other thread
Signal(sigp[1-mode],1);
WaitForSignal(sigc[mode]);
consume(buffs[mode],count);
Signal(sigc[1-mode],1);
}
}

Intel ARCHITECTURE IA-32 Specifications

General

Instruction Set	x86
Instruction Set Type	CISC
Memory Segmentation	Supported
Operating Modes	Real mode, Protected mode, Virtual 8086 mode
Max Physical Address Size	36 bits (with PAE)
Max Virtual Address Size	32 bits
Architecture	IA-32 (Intel Architecture 32-bit)
Addressable Memory	4 GB (with Physical Address Extension up to 64 GB)
Floating Point Registers	8 x 80-bit
MMX Registers	8 x 64-bit
SSE Registers	8 x 128-bit
Registers	General-purpose registers (EAX, EBX, ECX, EDX, ESI, EDI, ESP, EBP), Segment registers (CS, DS, SS, ES, FS, GS), Instruction pointer (EIP), Flags register (EFLAGS)
Floating Point Unit	Yes (x87)
