IA-32 Intel® Architecture Optimization
3-38
Note that this can be applied to both SIMD integer and SIMD
floating-point code.
If there are multiple consumers of an instance of a register, group the
consumers together as closely as possible. However, the consumers
should not be scheduled near the producer.
SIMD Optimizations and Microarchitectures
Pentium M, Intel Core Solo and Intel Core Duo processors have a
different microarchitecture than Intel NetBurst
®
microarchitecture. The
following sub-section discusses optimizing SIMD code targeting Intel
Core Solo and Intel Core Duo processors.
The register-register variant of the following instructions has improved
performance on Intel Core Solo and Intel Core Duo processor relative to
Pentium M processors. This is because the instructions consist of two
micro-ops instead of three. Relevant instructions are: unpcklps,
unpckhps, packsswb, packuswb, packssdw, pshufd, shuffps and shuffpd.
top_of_loop:
movq mm0, [A + eax]
pcmpgtw mm0, [B + eax]; Create compare mask
movq mm1, [D + eax]
pand mm1, mm0; Drop elements where A<B
pandn mm0, [E + eax] ; Drop elements where A>B
por mm0, mm1; Crete single word
movq [C + eax], mm0
add eax, 8
cmp eax, MAX_ELEMENT*2
jle top_of_loop
Example 3-21 Emulation of Conditional Moves (continued)

Intel ARCHITECTURE IA-32 Specifications

General

Instruction Set	x86
Instruction Set Type	CISC
Memory Segmentation	Supported
Operating Modes	Real mode, Protected mode, Virtual 8086 mode
Max Physical Address Size	36 bits (with PAE)
Max Virtual Address Size	32 bits
Architecture	IA-32 (Intel Architecture 32-bit)
Addressable Memory	4 GB (with Physical Address Extension up to 64 GB)
Floating Point Registers	8 x 80-bit
MMX Registers	8 x 64-bit
SSE Registers	8 x 128-bit
Registers	General-purpose registers (EAX, EBX, ECX, EDX, ESI, EDI, ESP, EBP), Segment registers (CS, DS, SS, ES, FS, GS), Instruction pointer (EIP), Flags register (EFLAGS)
Floating Point Unit	Yes (x87)
