IA-32 Intel® Architecture Optimization
1-30
Data is fetched 64 bytes at a time; the instruction and data translation
lookaside buffers support 128 entries. See Table 1-3 for processor cache
parameters.
Out-of-Order Core
The processor core dynamically executes µops independent of program
order. The core is designed to facilitate parallel execution by employing
many buffers, issue ports, and parallel execution units.
The out-of-order core buffers µops in a Reservation Station (RS) until
their operands are ready and resources are available. Each cycle, the
core may dispatch up to five µops through the issue ports.
Table 1-2 Trigger Threshold and CPUID Signatures for IA-32 Processor
Families
Trigger Thresh-
old Distance
(Bytes)
Extended
Model ID
Extended
Family ID Family ID Model ID
512 0 0 15 3, 4, 6
256 0 0 15 0, 1, 2
256 0069, 13, 14
Table 1-3 Cache Parameters of Pentium M, Intel
®
Core™ Solo and
Intel
®
Core™ Duo Processors
Level Capacity
Associativity
(ways)
Line
Size
(bytes)
Access
Latency
(clocks)
Write Update
Policy
First 32 KB 8 64 3 Writeback
Instruction 32 KB 8 N/A N/A N/A
Second
(model 9)
1 MB 8 64 9 Writeback
Second
(model 13)
2 MB 8 64 10 Writeback
Second
(model 14)
2 MB 8 64 14 Writeback

Intel ARCHITECTURE IA-32 Specifications

General

Instruction Set	x86
Instruction Set Type	CISC
Memory Segmentation	Supported
Operating Modes	Real mode, Protected mode, Virtual 8086 mode
Max Physical Address Size	36 bits (with PAE)
Max Virtual Address Size	32 bits
Architecture	IA-32 (Intel Architecture 32-bit)
Addressable Memory	4 GB (with Physical Address Extension up to 64 GB)
Floating Point Registers	8 x 80-bit
MMX Registers	8 x 64-bit
SSE Registers	8 x 128-bit
Registers	General-purpose registers (EAX, EBX, ECX, EDX, ESI, EDI, ESP, EBP), Segment registers (CS, DS, SS, ES, FS, GS), Instruction pointer (EIP), Flags register (EFLAGS)
Floating Point Unit	Yes (x87)
