Intel ARCHITECTURE IA-32 User Manual

IA-32 Instruction Latency and Throughput C
C-13
MOVLHPS
3
xmm, xmm 44 22 MMX_SHFT
MOVMSKPS r32, xmm 6 6 2 2 FP_MISC
MOVSS xmm, xmm 4 4 2 2 MMX_SHFT
MOVUPS xmm, xmm 6 6 1 1 FP_MOVE
MULPS xmm, xmm 7 6 4+1 2 2 2 FP_MUL
MULSS xmm, xmm 7 6 2 2 FP_MUL
ORPS
3
xmm, xmm 442222MMX_ALU
RCPPS
3
xmm, xmm 662442MMX_MISC
RCPSS
3
xmm, xmm 661221MMX_MISC,
MMX_SHFT
RSQRTPS
3
xmm, xmm 662442MMX_MISC
RSQRTSS
3
xmm, xmm 66 441MMX_MISC,
MMX_SHFT
SHUFPS
3
xmm, xmm,
imm8
662222MMX_SHFT
SQRTPS xmm, xmm 40 39 29+28 40 39 58 FP_DIV
SQRTSS xmm, xmm 32 23 30 32 23 29 FP_DIV
SUBPS xmm, xmm 5 4 4 2 2 2 FP_ADD
SUBSS xmm, xmm 5 4 3 2 2 1 FP_ADD
UCOMISS xmm, xmm 7 6 1 2 2 1 FP_ADD,
FP_MISC
UNPCKHPS
3
xmm,
xmm
663222MMX_SHFT
UNPCKLPS
3
xmm,
xmm
443222MMX_SHFT
XORPS
3
xmm, xmm 442222MMX_ALU
FXRSTOR 150
FXSAVE 100
See “Table Footnotes”
Table C-4 Streaming SIMD Extension Single-precision Floating-point
Instructions (continued)
Instruction Latency
1
Throughput Execution Unit
2

Intel ARCHITECTURE IA-32 Specifications

General

Instruction Set	x86
Instruction Set Type	CISC
Memory Segmentation	Supported
Operating Modes	Real mode, Protected mode, Virtual 8086 mode
Max Physical Address Size	36 bits (with PAE)
Max Virtual Address Size	32 bits
Architecture	IA-32 (Intel Architecture 32-bit)
Addressable Memory	4 GB (with Physical Address Extension up to 64 GB)
Floating Point Registers	8 x 80-bit
MMX Registers	8 x 64-bit
SSE Registers	8 x 128-bit
Registers	General-purpose registers (EAX, EBX, ECX, EDX, ESI, EDI, ESP, EBP), Segment registers (CS, DS, SS, ES, FS, GS), Instruction pointer (EIP), Flags register (EFLAGS)
Floating Point Unit	Yes (x87)
