Final Check Metering : Final Check Window
13 - 306
Displayed time
The slider enables adjustment of the time window that the History Graph displays
from 00:02:00s to 02:00:00s
Spatialization
Enable When ticked the spatial displays are active and shown in the Metering page.
Stereo display type The drop-down list offers the choice of: Phase Oscillo, Phase Stereo-meter and
VU stereo-meter.
Interpolate When ticked, the dots of the Phase Oscillo display will be interpolated. It is irrele-
vant to other meter displays
Loudness
Enable M (EBU mode Momentary : 400ms) enables the display of a loudness bargraph with integration time of
400ms, which corresponds to the momentary mode according to EBU R128.
Enable S (EBU mode Short : 3s) enables the display of a loudness bargraph with integration time of 3 seconds,
which corresponds to the short-term mode according to EBU R128.
Enable (custom integration time) enables the display of a loudness bargraph with user-selectable integration
time. The integration time is set with the
Integration time slider.
Enable LIaR (Loudness Integration and Range) enables the display of the loudness INT and LRA meter and
graph.
Standard ITU preset The drop-down list offers the choice of:
EBU Mode (R128) preset
ATSC A/85 & ITU 1864 preset
Customize...
When this option is selected the Target loudness and Gate threshold slid-
ers are active.
Scale The drop-down menu allows you to select one of the following scales for the loud-
ness bargraphs.
EBU +9 absolute (LUFS) This scale covers a range from -41 LUFS to -14 LUFS and is appropriate for
programs with small dynamic range.
EBU +18 absolute (LUFS)This scale covers a range from -59 LUFS to -5 LUFS and is appropriate for
programs with large dynamic range.
EBU +9 relative (LU) This scale covers the same range as EBU +9 absolute (LUFS), but is labeled
in LU, relative to -23 LUFS, hence from -18 LU to +9 LU. This scale is only
available with EBU Mode (R128) preset.
EBU +18 relative (LU) This scale covers the same range as EBU +18 absolute (LUFS), but is
labeled in LU, relative to -23 LUFS, hence from -36 LU to +18 LU. This scale is
only available with EBU Mode (R128) preset.
Target Loudness When Customize... is the selected preset the slider enables adjustment between
-30 LUFS and -20 LUFS.
Gate threshold When Customize... is the selected preset the slider enables values between -70LU
and -4 LU relative to be set. This threshold is relative to the selected Target loud-
ness. When the instantaneous loudness is below this threshold, the integrated
loudness calculation does not take the values into account until the instantaneous
loudness rises above the threshold again.
Peak hold time The slider varies the peak hold time between 0 and 19.5 seconds in half second
increments plus
on click. (Peak is held until the display is clicked.)
Color Range The two markers set the transition points between the color bands in the Loud-
ness graph displays. Defaults are -30LUFS and -16LUFS.
Show channels separately When ticked each channel will have its own LUFS bargraph display. Note: the his-
tory graph will NOT display the sum of all channels, when this button is ticked.
Instead, it shows the maximum channels loudness.
Show history graph When ticked the history graph is shown in the Metering page.
Displayed time The slider enables adjustment of the time window that the History Graph displays
from 00:02:00s to 02:00:00s
