Appendix IV Optional Features
Pyramix DSD / DXD / SACD
Hardware and Settings
Interfacing
Merging Technologies Horus
Merging Technologies Horus is the ideal solution to DSD and DXD interfacing.
The tables below shows the capabilities you can expect:
For complete information about Horus please see its own documentation and for full information about DSD /
DXD and SACD please see the forthcoming DSD / DXD / SACD Guide.
Legacy Mykerinos
DSD transmission works well with either AES-EBU or SDIF interfaces. Most converter manufacturers use SDIF. Only
dCS does SDIF and AES-EBU.
A further issue is the existence of two different AES-EBU supported DSD formats. The so called "Sony" and one
named "P3D." Merging Technologies support both of these. If you need to interface to both AES/EBU and SDIF two
cards will be required.
