TASCAM TDIF
The TASCAM TDIF daughter card offers 24 channels of I/O over 3 Tascam TDIF connections. Connection is via three
DB-25 connectors, One on the main card attached to the Mykerinos and two more on a separate bracket con-
nected via internal ribbon cable to the main card.
TASCAM TDIF I/O Option
A TASCAM TDIF format option bracket may be added to the ADAT I/O daughtercard and provides is available for 8
channels of TDIF I/O. The TDIF bracket connects to a socket on the ADAT card only. This daughter card cannot be
used in multi-board systems (since it utilizes the HTDM connector).
Daughter Card Support in Pyramix 8 MassCore
Ma ssCore &
Pmx 6.x
Non-Masscore &
Pmx 6.x
MassCore &
Pmx 6.x
Non-MassCore &
Pmx 6.x
MADI-I ? ? Not Supported Not Supported
MADI-II????
ADAT (Serials
20000 to 20299) ? ? Not Supported Not Supported
ADAT (Serials
20300 and +) ? (Note1) ? (Note1) ? (Note2) ?
AES-I????
AES-II????
SDIF????
TDIF????
DUAL ? ? ? Not Supported
Note 1: Full i/o of ADAT and SPDIF supported
Note 2: 16 ADAT i/o supported. No SPDIF i/o.
Daughter Cards
Standalone-Mono-board Multi-board
