Individual Meters Setup
Phase Meter
Enable When ticked the Phase Meters are active and shown in the Metering page.
Surround channel pair to monitorThe drop-down list offers the choice of any channel pair in a 6 track surround
bus to monitor for stereo phase. (This only affects the Surround Phase Meter.) This
setting can also be altered in the
Metering page, by simply right-clicking on the
Surround Phase-Meter.
PPM
Enable When ticked the PPMs are active and shown in the Metering page.
Type Label (Type II A (BBC)) Clicking on the label drops down a list of alternative PPM standards. Type I (DIN),
Type I
(Nordic), Type II A (BBC) and Type II B (EBU) or Customize...
When Customize is active the following five controls will be available:
0dBu calibration The slider enables adjustment between -24dBFS and 0dBFS.
Attack time The slider enables adjustment between 1ms and 15ms.
Release time The slider enables adjustment between 0.5s and 5.0s for a 20dB fall.
Slow mode available When ticked a Slow button will be shown on the PPM scales in the Metering win-
dow. Active when red. Clicking the button toggles on/off. When the button on the
PPM scale is off, nothing happens. When active, the attack time of the PPM is raised
significantly.
Attack time deviation in slow mode The slider sets the attack time when Slow is active from -50% to +50% of
the PPM slow-mode standard.
Peak hold time The slider sets the amount of time the peak value is held from 0.0s to 19.5s or on
click
, which requires a click on the meter to reset.
Show history graph When ticked the history graph is shown in the Metering page.
Displayed time The slider enables adjustment of the time window that the History Graph displays
from 00:02:00s to 02:00:00s
True Peak
Enable When ticked the TPMs are active and shown in the Metering page.
Type Label (Standard Preset) Clicking on the label drops down a list of alternative standards or Customize...
0dB calibration The slider enables offset adjustment between -12dBFS and +12dBFS
Release time The slider enables adjustment between 1ms and 1000ms.
Peak hold time The slider sets the amount of time the peak value is held from 0.0s to 19.5s or on
click
, which requires a click on the meter to reset.
Show history graph When ticked the history graph is shown in the Metering page.
Displayed time The slider enables adjustment of the time window that the History Graph displays
from 00:02:00s to 02:00:00s
VU Meter
Enable When ticked the PPMs are active and shown in the Metering page.
Standard (-14) preset The down arrow drops down a list of alternative presets. Standard (-14) preset,
North America / Australia (-18) preset and France (-20) preset.
0dB calibration The slider enables offset adjustment of the 0dB point between -24dBFS and 0dBFS.
Integration time The slider varies the integration time from 1ms to 1000ms.
Release time The slider varies the release time from 1ms to 1000ms. (for 20dB decay)
Peak hold time The slider sets the amount of time the peak value is held from 0.0s to 19.5s or on
click
, which requires a click on the meter to reset.
Show history graph When ticked the history graph is shown in the Metering page.
