Issue 4.0
SV9100 Programming Manual 2-65
06
Register Port
Assign the port number in which
the SIP messages are sent to on
the IPLE. This same port number
must be assigned in the SIP
Multiline terminals.
If this command is changed, it
requires a CPU reset.
When using NetLink (Program 51-
01-01) this Program is not used
and Program 51-17-01 will be
used per each System ID.
0~65535
5080
07
Encryption Mode
0 = Off
1 = On
0
08
Encryption Type
0 = Mode1
0
09
One Time Password
Up to 10 characters
(0~9,
, #)
None 10-46-07
10
Start Port
1~960
1 10-46-01
11
Multicast IP Address
Set the Multicast IP address so
that two or more main devices
don’t overlap on the same
network, or if Multicast is used by
other IP services.
224.0.0.0~
239.255.255.255
224.0.0.10
Input Data (Continued)
Item
No.
Item Input Data Default
Related
Program
To Next Page
