RM0090 Ethernet (ETH): media access control (MAC) with DMA controller

Doc ID 018909 Rev 4 1006/1422

Ethernet DMA receive descriptor list address register (ETH_DMARDLAR)

Address offset: 0x100C

Reset value: 0x0000 0000

The Receive descriptor list address register points to the start of the receive descriptor list.

The descriptor lists reside in the STM32F4xx's physical memory space and must be word-

aligned. The DMA internally converts it to bus-width aligned address by making the

corresponding LS bits low. Writing to the ETH_DMARDLAR register is permitted only when

reception is stopped. When stopped, the ETH_DMARDLAR register must be written to

before the receive Start command is given.

Ethernet DMA transmit descriptor list address register (ETH_DMATDLAR)

Address offset: 0x1010

Reset value: 0x0000 0000

The Transmit descriptor list address register points to the start of the transmit descriptor list.

The descriptor lists reside in the STM32F4xx's physical memory space and must be word-

aligned. The DMA internally converts it to bus-width-aligned address by taking the

corresponding LSB to low. Writing to the ETH_DMATDLAR register is permitted only when

transmission has stopped. Once transmission has stopped, the ETH_DMATDLAR register

can be written before the transmission Start command is given.

313029282726252423222120191817161514131211109876543210

RPD

rw_wt

Bits 31:0 RPD: Receive poll demand

When these bits are written with any value, the DMA reads the current descriptor pointed to

by the ETH_DMACHRDR register. If that descriptor is not available (owned by Host),

reception returns to the Suspended state and ETH_DMASR register bit 7 is not asserted. If

the descriptor is available, the Receive DMA returns to active state.

313029282726252423222120191817161514131211109876543210

SRL

rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw

Bits 31:0 SRL: Start of receive list

This field contains the base address of the first descriptor in the receive descriptor list. The

LSB bits [1/2/3:0] for 32/64/128-bit bus width) are internally ignored and taken as all-zero by

the DMA. Hence these LSB bits are read only.

313029282726252423222120191817161514131211109876543210

STL

rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
