DMA controller (DMA) RM0090
247/1422 Doc ID 018909 Rev 4
0x0070
DMA_S4CR
Reserved
CHSEL[2:0]
MBURST[1:0]
PBURST[1:0]
ACK
CT
DBM
PL[1:0]
PINCOS
MSIZE[1:0]
PSIZE[1:0]
MINC
PINC
CIRC
DIR
[1:0]
PFCTRL
TCIE
HTIE
TEIE
DMEIE
EN
Reset value 0000000000000000000000000000
0x0074
DMA_S4NDTR
Reserved
NDT[15:.]
Reset value 0000000000000000
0x0078
DMA_S4PAR PA[31:0]
Reset value 00000000000000000000000000000000
0x007C
DMA_S4M0AR M0A[31:0]
Reset value 00000000000000000000000000000000
0x0080
DMA_S4M1AR M1A[31:0]
Reset value 00000000000000000000000000000000
0x0084
DMA_S4FCR
Reserved
FEIE
Reserved
FS[2:0]
DMDIS
FTH
[1:0]
Reset value 0 100001
0x0088
DMA_S5CR
Reserved
CHSEL[2:0]
MBURST[1:0]
PBURST[1:0]
ACK
CT
DBM
PL[1:0]
PINCOS
MSIZE[1:0]
PSIZE[1:0]
MINC
PINC
CIRC
DIR[1:0]
PFCTRL
TCIE
HTIE
TEIE
DMEIE
EN
Reset value 0000000000000000000000000000
0x008C
DMA_S5NDTR
Reserved
NDT[15:.]
Reset value 0000000000000000
0x0090
DMA_S5PAR PA[31:0]
Reset value 00000000000000000000000000000000
0x0094
DMA_S5M0AR M0A[31:0]
Reset value 00000000000000000000000000000000
0x0098
DMA_S5M1AR M1A[31:0]
Reset value 00000000000000000000000000000000
0x009C
DMA_S5FCR
Reserved
FEIE
Reserved
FS[2:0]
DMDIS
FTH
[1:0]
Reset value 0 100001
0x00A0
DMA_S6CR
Reserved
CHSEL[2:0]
MBURST[1:0]
PBURST[1:0]
ACK
CT
DBM
PL[1:0]
PINCOS
MSIZE[1:0]
PSIZE[1:0]
MINC
PINC
CIRC
DIR[1:0]
PFCTRL
TCIE
HTIE
TEIE
DMEIE
EN
Reset value 0000000000000000000000000000
0x00A4
DMA_S6NDTR
Reserved
NDT[15:.]
Reset value 0000000000000000
0x00A8
DMA_S6PAR PA[31:0]
Reset value 00000000000000000000000000000000
0x00AC
DMA_S6M0AR M0A[31:0]
Reset value 00000000000000000000000000000000
0x00B0
DMA_S6M1AR M1A[31:0]
Reset value 00000000000000000000000000000000
0x00B4
DMA_S6FCR
Reserved
FEIE
Reserved
FS[2:0]
DMDIS
FTH
[1:0]
Reset value 0 100001
Table 44. DMA register map and reset values (continued)
Offset Register
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
