RM0090 DMA controller (DMA)

Doc ID 018909 Rev 4 248/1422

Refer to Table 2 on page 52 for the register boundary addresses.

0x00B8

DMA_S7CR

Reserved

CHSEL[2:0]

MBURST[1:0]

PBURST[1:0]

ACK

DBM

PL[1:0]

PINCOS

MSIZE[1:0]

PSIZE[1:0]

MINC

PINC

CIRC

DIR[1:0]

PFCTRL

TCIE

HTIE

TEIE

DMEIE

Reset value 000000000000 000000000000000

0x00BC

DMA_S7NDTR

Reserved

NDT[15:.]

Reset value 0000000000000000

0x00C0

DMA_S7PAR PA[31:0]

Reset value 00000000000000000000000000000000

0x00C4

DMA_S7M0AR M0A[31:0]

Reset value 00000000000000000000000000000000

0x00C8

DMA_S7M1AR M1A[31:0]

Reset value 00000000000000000000000000000000

0x00CC

DMA_S7FCR

Reserved

FEIE

Reserved

FS[2:0]

DMDIS

FTH

[1:0]

Reset value 0 100001
