4-16 Phaser 6180MFP Multifunction Printer Service Manual
General Troubleshooting
ROS Ready
(Do not use)
ROS Ready
■ OFF
■ L - 0
■ H - 0
Tests the Laser Unit.
Interlock Switch Interlock Switch
■ OFF
■ L - 0
■ H - 0
Tests the Front Cover Interlock Switch.
CRU Sensor (Y) CRU Sensor Y
■ OFF
■ L - 0
■ H - 0
Tests the Yellow Print Cartridge Sensor.
CRU
Sensor (M)
CRU Sensor M
■ OFF
■ L - 0
■ H - 0
Tests the Magenta Print Cartridge
Sensor.
CRU Sensor (K) CRU Sensor K
■ OFF
■ L - 0
■ H - 0
Tests the Black Print Cartridge Sensor.
CRU Sensor (C) CRU Sensor C
■ OFF
■ L - 0
■ H - 0
Tests the Cyan Print Cartridge Sensor.
Tray 3 Low
Paper
(Do not use)
Tray 3 Low Paper
■ OFF
■ L - 0
■ H - 0
Tests the Tray 3 Low Paper Sensor.
Tray 3 No Paper Tray 3 No Paper
■ OFF
■ L - 0
■ H - 0
Tests the Tray 3 No Paper Sensor.
Duplex Fan
Alarm
(Do not use)
Duplex Fan Alarm
■ OFF
■ L - 0
■ H - 0
Tests Duplex Fan Alarm.
Tray 3 Feed
Motor Alarm
(Do not use)
Tray 3 FdMotorAlm
■ OFF
■ L - 0
■ H - 0
Tests Tray 3 Feed Motor Alarm.
MPT No Paper MPT No Paper
■ OFF
■ L - 0
■ H - 0
Tests the Tray 1 No Paper Sensor.
Printer Diag Test Table (continued)
Test Control Panel Display Test Description

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
