Xerox Phaser 6180MFP Service Manual

Phaser 6180MFP Multifunction Printer Service Manual 4-17
General Troubleshooting
Tray 2 No Paper Tray 2 No Paper
■ OFF
■ L - 0
■ H - 0
Tests the Tray 2 No Paper Sensor.
Main Motor
Alarm
(Do not use)
Main Motor Alarm
■ OFF
■ L - 0
■ H - 0
Tests Main Motor Alarm.
Sub Motor
Alarm
(Do not use)
Sub Motor Alarm
■ OFF
■ L - 0
■ H - 0
Tests Sub Motor Alarm.
Fan Alarm
(Do not use)
FAN Alarm
■ OFF
■ L - 0
■ H - 0
Tests Fan Alarm.
Tray 2 Motor
Alarm
(Do not use)
Tray2 Motor Alarm
■ OFF
■ L - 0
■ H - 0
Tests Tray 2 Motor Alarm.
Deve Motor
Alarm
(Do not use)
DEVE Motor Alarm
■ OFF
■ L - 0
■ H - 0
Tests Developer Motor Alarm.
Tray 2 Paper
Size
Tray2 Paper Size
■ OFF
■ L - 0
■ H - 0
■ Paper Size (Letter -
8.5x11)
Tests the Tray 2 Paper Size Switch.
Tray 3 Paper
Size
Tray3 Paper Size
■ OFF
■ L - 0
■ H - 0
■ Paper Size (Legal -
8.5x14)
Tests the Tray 3 Paper Size Switch.
Motor Test <Press the Up or Down
button to move from one
item to another>
Tests the Motors of the printer.
Main Motor
(Full2)
Main Motor (FULL2)
■ Ready
■ EXEC
Tests the Main Motor.
Main Motor
(Full1)
Main Motor (FULL1)
■ Ready
■ EXEC
Printer Diag Test Table (continued)
Test Control Panel Display Test Description

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
