4-18 Phaser 6180MFP Multifunction Printer Service Manual
General Troubleshooting
Main Motor
(Half)
Main Motor (HALF)
■ Ready
■ EXEC
Main Motor
(Low)
Main Motor (LOW)
■ Ready
■ EXEC
Sub Motor
(Full2)
Sub Motor (FULL2)
■ Ready
■ EXEC
Tests the Sub Motor.
Sub Motor
(Full1)
Sub Motor (FULL1)
■ Ready
■ EXEC
Sub Motor
(Half)
Sub Motor (HALF)
■ Ready
■ EXEC
Sub Motor
(Low)
Sub Motor (LOW)
■ Ready
■ EXEC
Tray 2 Motor
(Full2)
Tray 2 Motor (FULL2)
■ Ready
■ EXEC
Tests the Tray 2 Motor.
Tray 2 Motor
(Full1)
Tray 2 Motor (FULL1)
■ Ready
■ EXEC
Tray 2 Motor
(Half)
Tray 2 Motor (HALF)
■ Ready
■ EXEC
Tray 2 Motor
(Low)
Tray 2 Motor (LOW)
■ Ready
■ EXEC
Deve Motor
(Full2)
Deve Motor (FULL2)
■ Ready
■ EXEC
Tests the Developer Motor.
Deve Motor
(Full1)
Deve Motor (FULL1)
■ Ready
■ EXEC
Deve Motor
(Half)
Deve Motor (HALF)
■ Ready
■ EXEC
Duplex Motor
(High)
Duplex Motor (HIGH)
■ Ready
■ EXEC
Tests the Duplex Motor.
Printer Diag Test Table (continued)
Test Control Panel Display Test Description
