Xerox Phaser 6180MFP Service Manual

Phaser 6180MFP Multifunction Printer Service Manual 4-19
General Troubleshooting
Duplex Motor
(Full2)
Duplex Motor (FULL2)
■ Ready
■ EXEC
Duplex Motor
(Full1)
Duplex Motor (FULL1)
■ Ready
■ EXEC
Duplex Motor
(Half)
Duplex Motor (HALF)
■ Ready
■ EXEC
Duplex Motor
(Low)
Duplex Motor (LOW)
■ Ready
■ EXEC
Tray 3 Feed
Motor (Full2)
Tray 3 Feed Motor
(FULL2)
■ Ready
■ EXEC
Tests the Tray 3 Feed Motor.
Tray 3 Feed
Motor (Full1)
Tray 3 Feed Motor
(FULL1)
■ Ready
■ EXEC
Tray 3 Feed
Motor (Half)
Tray 3 Feed Motor
(HALF)
■ Ready
■ EXEC
Tray 3 Feed
Motor (Low)
Tray 3 Feed Motor
(LOW)
■ Ready
■ EXEC
Fan (High) Fan (HIGH)
■ Ready
■ EXEC
Tests the printer Fan.
Fan (Low) Fan (LOW)
■ Ready
■ EXEC
Yellow Toner
Motor
Yellow Toner Motor
■ Ready
■ EXEC
Tests the yellow Toner Motor.
Magenta Toner
Motor
Magenta Toner Motor
■ Ready
■ EXEC
Tests the magenta Toner Motor.
Cyan Toner
Motor
Cyan Toner Motor
■ Ready
■ EXEC
Tests the cyan Toner Motor.
Printer Diag Test Table (continued)
Test Control Panel Display Test Description

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
