Xerox Phaser 6180MFP Service Manual

4-20 Phaser 6180MFP Multifunction Printer Service Manual
General Troubleshooting
Black Toner
Motor
Black Toner Motor
■ Ready
■ EXEC
Tests the black Toner Motor.
Regi Clutch Regi Clutch
■ Ready
■ EXEC
Tests the Registration Clutch.
Tray1 (MPT)
Turn Clutch
Tray1(MPT) Turn Clutch
■ Ready
■ EXEC
Tests the Tray 1 Turn Clutch.
Tray 1 (MPT)
Feed Solenoid
Tray1(MPT) Feed
Solenoid
■ Ready
■ EXEC
Tests the Tray 1 Feed Solenoid.
Tray 2 Feed
Clutch
Tray 2 Feed Clutch
■ Ready
■ EXEC
Tests the Tray 2 Feed Clutch.
Tray 3 Feed
Clutch
Tray 3 Feed Clutch
■ Ready
■ EXEC
Tests the Tray 3 Feed Clutch.
Tray 3 Turn
Clutch
Tray 3 Turn Clutch
■ Ready
■ EXEC
Tests the Tray 3 Turn Clutch.
Duplex Clutch Duplex Clutch
■ Ready
■ EXEC
Tests the Duplex Clutch.
ADC (TCD)
Sensor
Solenoid
ADC (TCD) Sensor
Solenoid
■ Ready
■ EXEC
Tests the ADC Sensor Solenoid.
ADC (TCD)
Sensor LED
ADC (TCD) Sensor LED
■ Ready
■ EXEC
Tests the ADC Sensor LED.
OHP Sensor
LED
(Do not use)
OHP Sensor LED
■ Ready
■ EXEC
Tests the OHP Sensor LED.
Drum Erase
Lamp K
Drum Erase Lamp K
■ Ready
■ EXEC
Tests the black Erase Lamp.
Drum Erase
Lamp YMC
Drum Erase Lamp YMC
■ Ready
■ EXEC
Tests the yellow, magenta, and cyan
Erase Lamps.
Exit Clutch Exit Clutch
■ Ready
■ EXEC
Tests the Exit Clutch.
Printer Diag Test Table (continued)
Test Control Panel Display Test Description

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
