Xerox Phaser 6180MFP Service Manual

Phaser 6180MFP Multifunction Printer Service Manual 4-21
General Troubleshooting
Duplex Fan Duplex Fan
■ Ready
■ EXEC
Tests the Duplex Fan.
NVM Settings <Press the Up or Down
button to move from one
item to another>
<Press the Cancel button
to move one level up the
menu>
<Press the Set button to
move to the execution
level>
Edits, saves, loads, and prints NVRAM
information.
Edit NVM
(Do not use)
Edit NVM
■ Ad0000=00000000*
■ Please wait
<Press the Left or Right
button to move the
cursor>
<Press the Up or Down
button to change the
value at the cursor>
<Press the OK button to
save the value in Engine
NVM>
<Press the Exit button to
move one level up the
menu>
Displays the current NVRAM value.
Use this function to edit NVRAM
information.
Save NVM to
ESS
SaveNVM to ESS
■ SaveNVM to ESS OK?
■ Processing
■ Saved
■ Please wait
<Press the OK button to
save the value in the
Controller NVM>
<Press the Exit button to
move one level up the
menu>
Saves the NVRAM information of the
Engine in the Controller. NVRAM
addresses to be saved are as follows:
1000-10FF, Total: 256Byte
Note: Information saved in the
Controller NVM can be initialized using
Clear All NVM.
Printer Diag Test Table (continued)
Test Control Panel Display Test Description

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
