Xerox Phaser 6180MFP Service Manual

4-38 Phaser 6180MFP Multifunction Printer Service Manual
General Troubleshooting
Line Voltage Line Voltage
■ Value[1.0V]: 000
■ Now Sampling
This test measures the telephone
voltage. The voltage displayed in this
test varies from country to country.
The state is ON HOOK during the CE
mode.
Cycle at repeat: 500ms
Line Current Line Current
■ Value[1.1mA]: 000
■ Now Sampling
This test measures the telephone line
amperage. The state is OFF HOOK
during the CE mode.
Cycle at repeat: 500ms
Note: The minimum guaranteed
current in the United States is 20mA.
Information Provides Scan Counter and Firmware versions information.
Scan Counter Scan Counter
■ FB:0x00000000
■ ADF:0x00000000
Displays the scan counter value.
■ FB: Scanning of document glass
mode.
■ ADF: Scanning of ADF mode.
Version Version
■ Main:nnnnnnnnnnnn
■ Param:nnnnnnnnnnnn
■ Boot:nnnnnnnnnnnn
■ Dload:nnnnnnnnnnnn
■ IIT:nnnnnnnnnnnn
■ Panel:nnnnnnnnnnnn
Displays the software version.
■ Main: Main program version
■ Param: Parameter version
■ Boo: Boo program version
■ Dload: Down load program version
■ IIT: Scanner and ADF control
program versions
■ Panel: Control panel program
version
Scanner
Maintenance
White Balance White Balance Enables automatic calibration of the
correction value for document glass
scanning (FB) and ADF scanning.
Auto Adjust
(FB)
Auto Adjust (FB)
■ Ready
■ Now Adjusting
■ Adjust OK/Adjust NG
Use to configure the White Balance by
correcting C2 value for document glass
with auto-adjustment.
Auto Adjust
(ADF)
Auto Adjust (ADF)
■ Ready
■ Now Adjusting
■ Adjust OK/Adjust NG
Use to configure the White Balance by
correcting C2 value for ADF with auto-
adjustment.
Parameter Parameter
■ Index[Hex]: 00
■ Value[Hex]:*00
<Press the Up or Down
button to change the
value at the cursor>
<Press the Left or Right
button to move the
cursor>
Enables manual calibration of the
registration adjustment value or
correction value.
Use this function to enter the
correction value when replacing the
scanner (refer to “Scanner Calibration”
on page 6-8).
Fax/Scanner Diag
Test Control Panel Display Test Description

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
