412-03-17 Air Conditioning 412-03-17
REMOVAL AND INSTALLATION
Evaporator Core Orifice (34 624 0)
Special Tool(s)
Disconnect Tool, Spring Lock
Coupling 1/2 inch (blue)
412-027 (34-001)
Remover/Installer, Fixed
Orifice
412-034 (34-004)
Special Tool(s)
Remover, Broken Orifice
412-035 (34-005)
Removal
1. Drain the air conditioning system. For
additional information, refer to Section 412-
00.
2. Detach the coolant expansion tank and
secure it to one side.
3. Remove the weather strip rubber seal.
E6718 EN 07/2001 2002 Bantam
