501-16-31 Wipers and Washers 501-16-31
REMOVAL AND INSTALLATION
Windshield Washer Pump (32 624 0)
Removal
1. Undo the right-hand front wheel nuts.
2. Raise the vehicle. For additional
information,
refer to Section 100-02.
3. Detach the right-hand front wheel.
4. Remove the wheelhouse cover.
5. Remove the washer pump.
1. Disconnect the hoses and drain the
washer reservoir.
2. Disconnect the plug.
• Pull out the washer pump (push fit).
• Remove the rubber grommet from the
washer reservoir.
Installation
1. NOTE: Coat the rubber grommet with soap
solution before fitting it.
Refit the components in reverse order.
E4469 EN 07/2001 2002 Bantam
