501-16-33 Wipers and Washers 501-16-33
REMOVAL AND INSTALLATION
Windshield Washer Reservoir (32 622 0)
Removal
1. Unscrew the nuts on the A-pillar, working
from the inside.
2. NOTE: There is no need to empty the coolant
expansion tank.
Detach the coolant expansion tank.
• Remove the single screw.
• Unhook the coolant expansion tank from
its bracket.
3. Pull off the filler neck.
4. Raise the vehicle. For additional
information,
refer to Section 100-02.
E925 EN 07/2001 2002 Bantam
