417-01-6
Exterior Lighting
417-01-6
DESCRIPTION AND OPERATION
Central Junction Box (CJ
B)- top view
Item
Description
1 Ignition
relay
2 Windshield
wiper
relay
3 Horn
relay
4
A/C switch relay
5 Not
used
Item
Description
6
WOT relay (petrol)
7
Power hold relay
8
Fuel pump relay (petrol)
9
Low beam relay
10
High beam relay
E6750 EN
07/2001 2002 Bantam
