501-11-2 Glass, Frames and Mechanisms 501-11-2
DIAGNOSIS AND TESTING
Glass, Frames and Mechanisms
Refer to Wiring Diagrams Cell: 50111, for
schematic and connector information.
Inspection and Verification
1. Verify the customer concern.
2. Visually inspect for obvious signs of
mechanical or electrical damage.
Visual Inspection Chart
Mechanical
Electrical
• Window seal
• Door window frame
• Fuse(s)
• Electrical
connector(s)
• Switch(s)
• Circuit(s)
3. If an obvious cause for an observed or
reported concern is found, correct the cause
(if possible) before proceeding to the next
step.
4. If the cause is not visually evident, verify the
symptom and refer to the Symptom Chart.
Symptom Chart
Condition
Possible Sources
Action
• All power windows are inopera-
tive
• Driver power window control
switch.
• CARRY OUT the Driver Power
Window Control Switch Compo-
nent Test.
REFER to the Wiring
Diagrams.
• Single power window is inopera-
tive - driver side
• Driver power window control
switch
• CARRY OUT the Driver Power
Window Control Switch Compo-
nent Test.
REFER to the Wiring
diagrams.
• Circuit(s).
• Driver power window motor.
• Go To Pinpoint Test A
• Single power window is inopera-
tive - passenger side
• Passenger power window con-
trol switch.
• CARRY OUT the Passenger
Power Window Control Switch
Component
Test.
REFER to the
Wiring Diagrams.
• Driver power window control
switch.
• CARRY OUT the Driver Power
Window Control Switch Compo-
nent Test.
REFER to the Wiring
Diagrams.
• Circuit(s).
• Passenger power window mo-
tor.
• Go To Pinpoint Test B
Pinpoint Tests
NOTE: Use a digital multimeter for all electrical
measurements.
E9411 EN 08/2001 2002 Bantam
