303-01B-91 Engine — 1.6L / 1.3L RoCam 303-01B-91
DISASSEMBLY (CONTINUED)
E6643 EN 07/2001 2002 Bantam
12. Remove the intake manifold.
Vehicles with 1.3L engine.
13. Remove the knock sensor.
Note: Inlet manifold removed for clarity.
All vehicles
14.
CAUTION: Do not pull the cable when
removing the spark plug connector. If
necessary remove the ignition cables
from the ignition coil to prevent
kinking the cables. Turn the spark
plug connectors before removing to
loosen the seal.
CAUTION: Pull off the spark plug
connectors in line with the spark
plugs (for bent spark plug
c
onnectors use Special Tool 303-
6
22).
Remove the spark plugs.
