303-01D-102 Engine — 1.8L Diesel - Endura DE 303-01D-102
DISASSEMBLY (CONTINUED)
E6007 EN 09/2001 2002 Bantam
Engines with mechanical timing belt tensioner
17. WARNING: The timing belt tensioner
is spring-loaded.
Remove the timing belt tensioner and the
camshaft timing belt pulley.
1. Timing belt tensioner bolts
2. Camshaft timing belt pulley bolts
All vehicles
18. Remove the engine mounting bracket.
19. Remove the timing belt side cover.
20. Remove the oil dipstick tube.
