MPC5604B/C Microcontroller Reference Manual, Rev. 8
Freescale Semiconductor 153
CORE_DBG Processor is in Debug mode indicator — This bit is set while the processor is in debug mode.
0 The processor is not in debug mode
1 The processor is in debug mode
SMR SAFE mode request from MC_RGM is active indicator — This bit is set if a hardware SAFE mode
request has been triggered. It is cleared when the hardware SAFE mode request has been cleared.
0 A SAFE mode request is not active
1 A SAFE mode request is active
FMPLL_SC FMPLL State Change during mode transition indicator — This bit is set when the frequency
modulated phase locked loop is requested to change its power up/down state. It is cleared when the
frequency modulated phase locked loop has completed its state change.
0 No state change is taking place
1 A state change is taking place
FXOSC_SC FXOSC State Change during mode transition indicator — This bit is set when the fast external crystal
oscillator (4-16 MHz) is requested to change its power up/down state. It is cleared when the fast
external crystal oscillator (4-16 MHz) has completed its state change.
0 No state change is taking place
1 A state change is taking place
FIRC_SC FIRC State Change during mode transition indicator — This bit is set when the fast internal RC
oscillator (16 MHz) is requested to change its power up/down state. It is cleared when the fast internal
RC oscillator (16 MHz) has completed its state change.
0 No state change is taking place
1 A state change is taking place
SYSCLK_S
W
System Clock Switching pending status —
0 No system clock source switching is pending
1 A system clock source switching is pending
DFLASH_SC DFLASH State Change during mode transition indicator — This bit is set when the DFLASH is
requested to change its power up/down state. It is cleared when the DFLASH has completed its state
change.
0 No state change is taking place
1 A state change is taking place
CFLASH_SC CFLASH State Change during mode transition indicator — This bit is set when the CFLASH is
requested to change its power up/down state. It is cleared when the DFLASH has completed its state
change.
0 No state change is taking place
1 A state change is taking place
CDP_PRPH
_0_143
Clock Disable Process Pending status for Peripherals 0…143 — This bit is set when any peripheral
has been requested to have its clock disabled. It is cleared when all the peripherals which have been
requested to have their clocks disabled have entered the state in which their clocks may be disabled.
0 No peripheral clock disabling is pending
1 Clock disabling is pending for at least one peripheral
CDP_PRPH
_96_127
Clock Disable Process Pending status for Peripherals 96…127 — This bit is set when any peripheral
appearing in
ME_PS3 has been requested to have its clock disabled. It is cleared when all these
peripherals which have been requested to have their clocks disabled have entered the state in which
their clocks may be disabled.
0 No peripheral clock disabling is pending
1 Clock disabling is pending for at least one peripheral
Table 8-10. Debug Mode Transition Status Register (ME_DMTS) Field Descriptions (continued)
Field Description
